48K audio sampling rate and 20Hz ~ 20KHz frequency response
USB recording, controller monitor, advanced noise cancellation technology
Can drive 2x120W POE speaker
Features
The unique BRONX-LINK digital ring network technology achieve full-digital signal transmission and processing.
One CAT5e cable to transmit up 64 channels audio and othersignals.
All microphone units support audio, ID independent output. Working with voice recognition system to achieve voice role separation.
High-fidelity sound quality by lossless audio transmission technology, 48K audio sampling rate and 20Hz ~ 20KHz frequency response THD at nominal level- < 0.1 % , Dynamic range- >98 dBA , Signal-to-noise ratio - >96.
A single conference controller can realize the independent control and merging of 4 conference rooms, can handle the cascade of multiple conference controllers to realize the merging and separation of larger conference rooms (Optional).
“Hand-in-Hand-Loop-Network” connection makes the system always working perfectly no matter changing discussion unit or having any malfunctioned units.
The sensitivity of the unit microphone and 8 segment equalizer EQ adjusted independently.
Conference controller can output 16 segment equalized EQ to achieve sound field adjustment; pressure limit, which can recognize the noise gate passed by human voice. AGC automatic volume gain control; AFC automatic feedback suppression and auto-mix technology.
Sound output by separated zonesfunction, each zone is automatically adjusted according to the volume of the position of the microphone, achieve longer distances pickup without whistle.
Echo cancellation, remote two-way real-time call with another conference controller or another third-party video conferencing terminal.
USB recording, controller monitor, advanced noise cancellation technology to realize clearer recording.
System date, time management, and support count-down speech.
Optional DANTE output module with other DANTE equipment used (expandable up to 12 I/O ports).
Can drive 2x120W POE speaker, through extension main unit, support up to 16 POE speakers.
Control & Indicators
LCD display to show all the operations and results.
