• All-in-One Design All-in-One design, can output 3 channel (IP,HDMI,SDI ) HD 1080P video at the same time.
  • Intelligent Teaching Tracking Built-in leading image recognition and tracking algorithm can achieve smooth and natural tracking effect without any auxiliary positioning camera or tracking host. Different cameras are assembled before production, so as to achieve teacher tracking or student tracking.
  • Changeable Lens Panorama camera lens, compatible with M12 mount lens, can be replaced. Product can be used on different sizes of classrooms.
  • Adjustable Viewing Angle Panorama camera can adjust viewing angle in vertical(-15° ~ 0°), so as to convenient for installation and debugging.

  • Same Image Style Both panorama camera and close-up camera use the same ISP, make sure the image output have the same brightness, color, style, etc.
  • Easy Configuration Easy to make a configuration for tracking parameters by connecting to Ethernet directly. Just some basic parameters will be configured, and engineering debugging time for Cost Saving
  • 72.5° Wide-angle Lens + 12x optical Zoom Close-up camera use 72.5° wide-angle high quality lens, support 12x optical zoom, and 16x digital zoom.
  • 1080P Full HD Apply Panasonic's high quality HD CMOS sensors of 1/2.8 inch, 2.07 million effective pixels, so as to reach maximum 1920 x 1080 resolution and achieve quality image.
  • Ultra-high Frame Rate The output frame rate is up to 60fps in 1080P.
  • AAC Audio Encoding Close-up camera support AAC audio encoding, better sound quality and smaller bandwidth
