BRONX Pneumatic Pop-Up Box

Model: BL0416

  • Panel size: 120*120mm
  • Open Slot: 100*100mm
  • Height: 63mm
  • Flush Mount
  • Attractive appearance with Mechanical Locking System
  • Easy installation
  • Modules can be changed
  • Having 1 HDMI, 1 VGA, 1 3.5 MM Audio Jack, 1 LAN,1 USB, 1 Universal Power.
  • Power Point (220-240V) with cables & Connectors as require etc.

background

Bronx Desktop Flip Top BOX
Model: A0203

Description

  • Pop Up Desktop Socket Box 1 Power; 2 Data; 1 VGA; 1 Audio; 1 Video
  • Modules: 1 Universal Power; 2 Data; 1 VGA; 1 Audio; 1 Video Panel
  • Product Size: 145x130x78mm
  • Open Hole Size: 130x115mm
BRONX Desktop Flip Top BOX Model: A0203

Bronx Controllable Motorized Flip Up Box
Model: BJN207E

Description

  • Motorized Hidden Connection Box
  • Auto Reverse Photoelectric Safety Sensors
  • Brushed Black Aluminium Body
  • Elegant Looks to suite Board Room Decor
  • Noise Less Operation
  • Controllable through Crestron/AMX/Extron etc
  • Power Indicator Light Locking Device, Smooth Motorised Support Structure, VGA with Audio through cable and wirelessly both, HDMI, C-Video, Audio, Network, Telephone, Power etc. with Control Port builtin, Neat & elegant topside, Input voltage: 110V-220V / 50-60Hx, RCA, 3.5 mm Audio Jack, USB, Surface Mountable Enclosure for Cables with cables & connectors as required etc. all complete.
Technical Specifications
  • Three Pin Universal Power Socket
  • Data / LAN Socket for Internet / Ethernet
  • VGA (15-Pin D-Sub) Connectivity
  • HDMI Interface
  • Composite Video (RCA) Socket
  • PC Stereo Audio
  • Package Size: 480×180×190mm
  • Cut-out Size: 380*110*103mm
  • 220V/50 Hz. AC Power
  • 180V-220V/50HZ
BRONX Controllable Motorized Flip Up Box Model: BJN207E

Bronx Desktop Cable Cubby
Model: L0261

Description

  • Product: Drawbench Silver, Black color
  • Size of the product is 266*130*78mm
  • Hole size: 251*115mm
  • Material: Aluminum alloy/cold relled steel
BRONX Desktop Cable Cubby Model: L0261

Bronx Desktop Cable Cubby
Model: BL0261

Description

  • Product: 6 Slot with 2x un-switched AC power 110v-240v 50/60Hz, 10A Outlet
  • Top Panel Size : 217x138x2 mm, Out of Box Size : 204x125x119 mm
  • Hole size: 251*115mm
  • Material: Aluminium alloy/cold rolled steel
BRONX Desktop Cable Cubby Model: BL0261

BRONX Desktop POP-UP-BOX
Model: BIB-2

Description

  • Power Socket, VGA receptacle, video 3.5 mm stereo socket, Audio frequency socket, Dual-RCA video socket, Dual-Net socket.
  • Desktop Hidden Connection Box, Mechanical Locking Device, Smooth Pneumatic Support Structure, HDMI, VGA,C-Video, Audio, Network, Telephone, Power etc.
  • Control Switch builtin, Neat & elegant topside, input voltage: 110V- 220V/50-60Hz, Surface Mountable Enclosure for Cables APPs.
BRONX Desktop POP-UP-BOX Model: BIB-2
